HLP-SV系 HLPSV00D421A 1×200-240V 50/60Hz 0.4 1.0 2.5 0.4
HLPSV0D7521A 1×200-240V 50/60Hz 0.75 2.0 4.2 0.75
HLPSV01D521A 1×200-240V 50/60Hz 1.5 2.8 6.8 1.5
HLPSV02D221A 1×200-240V 50/60Hz 2.2 ** ** 2.2
HLPSV03D721A 1×200-240V 50/60Hz 3.7 ** ** 3.7
HLPSV00D423A 3×200-240V 50/60Hz 0.4 1.0 2.5 0.4
HLPSV0D7523A 3×200-240V 50/60Hz 0.75 2.0 4.2 0.75
HLPSV01D523A 3×200-240V 50/60Hz 1.5 2.8 6.8 1.5
HLPSV02D223A 3×200-240V 50/60Hz 2.2 ** ** 2.2

注：** 為HOLIP即將海利普變頻器HOLIP-F（紡紗機專用）
HLPF00D423B 單三相220V 50Hz 0.4 1.0 2.5 0.4
HLPF0D7523B 單三相220V 50Hz 0.75 2.0 5.0 0.75
HLPF01D523B 單三相220V 50Hz 1.5 2.8 7.0 1.5
HLPF02D223B 單三相220V 50Hz 2.2 4.0 10 2.2
HLPF0D7543B 3Φ380V 50Hz 0.75 2.2 2.7 0.75
HLPF01D543B 3Φ380V 50Hz 1.5 3.2 4.0 1.5
HLPF02D243B 3Φ380V 50Hz 2.2 4.0 5.0 2.2
HLPF03D743B 3Φ380V 50Hz 3.7 6.8 8.5 3.7
HLPF05D543B 3Φ380V 50Hz 5.5 10 12.5 5.5
HLPF07D543B 3Φ380V 50Hz 7.5 14 17.5 7.5
HLPF001143B 3Φ380V 50Hz 11 19 24 11
HLPF001543B 3Φ380V 50Hz 15 26 33 15
HLPF18D543B 3Φ380V 50Hz 18.5 32 40 18.5
HLPF002243B 3Φ380V 50Hz 22 37 47 22
HLPF003043B 3Φ380V 50Hz 30 52 65 30

海利普變頻器HOLIP-J（注塑機專用）

?產品尺寸
型號 A B C D E
HLPJ001143B 610 305 245 275 180
HLPJ001543B
HLPJ18D543B
HLPJ002243B 770 290 300 260 250
HLPJ003043B
HLPJ003743B 980 345 350 315 300
HLPJ004543B 1140 430 350 400 300
HLPJ005543B
HLPJ007543B 1140 520 350 490 300

海利普變頻器HOLIP-M（磨床專用）

HLPM00D423B 單三相220V 50Hz 0.4 1.0 2.5 0.4
HLPM0D7523B 單三相220V 50Hz 0.75 2.0 5.0 0.75
HLPM01D523B 單三相220V 50Hz 1.5 2.8 7.0 1.5
HLPM02D223B 單三相220V 50Hz 2.2 4.0 10 2.2
HLPM0D7543B 3Φ380V 50Hz 0.75 2.2 2.7 0.75
HLPM01D543B 3Φ380V 50Hz 1.5 3.2 4.0 1.5
HLPM02D243B 3Φ380V 50Hz 2.2 4.0 5.0 2.2
HLPM03D743B 3Φ380V 50Hz 3.7 6.8 8.5 3.7
HLPM05D543B 3Φ380V 50Hz 5.5 10 12.5 5.5
HLPM07D543B 3Φ380V 50Hz 7.5 14 17.5 7.5
HLPM001143B 3Φ380V 50Hz 11 19 24 11
HLPM001543B 3Φ380V 50Hz 15 26 33 15
HLPM18D543B 3Φ380V 50Hz 18.5 32 40 18.5
HLPM002243B 3Φ380V 50Hz 22 37 47 22
HLPM003043B 3Φ380V 50Hz 30 52 65 30
HLPM003743B 3Φ380V 50Hz 37 64 80 37
HLPM004543B 3Φ380V 50Hz 45 72 91 45
HLPM005543B 3Φ380V 50Hz 55 84 110 55

海利普變頻器HOLIP-P（恒壓供水專用）

容量(KVA) 輸出電流(A) 適 用電 機(KW)
HLPP001143C 3Φ380V 50Hz 11 19 24 11
HLPP001543C 3Φ380V 50Hz 15 26 33 15
HLPP18D543C 3Φ380V 50Hz 18.5 32 40 18.5
HLPP002243C 3Φ380V 50Hz 22 37 47 22
HLPP003043C 3Φ380V 50Hz 30 52 65 30
HLPP003743C 3Φ380V 50Hz 37 64 80 37
HLPP004543C 3Φ380V 50Hz 45 72 91 45

海利普變頻器HOLIP-H（中頻機專用）
?功率范圍：0.4KW~3.7KW（單、三相220V）；

HLPH00D423B 單三相220V 50Hz 0.4 1.0 2.5 0.4
HLPH0D7523B 單三相220V 50Hz 0.75 2.0 5.0 0.75
HLPH01D523B 單三相220V 50Hz 1.5 2.8 7.0 1.5
HLPH02D223B 單三相220V 50Hz 2.2 4.0 10 2.2
HLPH0D7543B 3Φ380V 50Hz 0.75 2.2 2.7 0.75
HLPH01D543B 3Φ380V 50Hz 1.5 3.2 4.0 1.5
HLPH02D243B 3Φ380V 50Hz 2.2 4.0 5.0 2.2
HLPH03D743B 3Φ380V 50Hz 3.7 6.8 8.5 3.7
HLPH05D543B 3Φ380V 50Hz 5.5 10 12.5 5.5
HLPH07D543B 3Φ380V 50Hz 7.5 14 17.5 7.5
HLPH001143B 3Φ380V 50Hz 11 19 24 11
HLPH001543B 3Φ380V 50Hz 15 26 33 15
HLPH18D543B 3Φ380V 50Hz 18.5 32 40 18.5
HLPH002243B 3Φ380V 50Hz 22 37 47 22
HLPH003043B 3Φ380V 50Hz 30 52 65 30
HLPH003743B 3Φ380V 50Hz 37 64 80 37
HLPH004543B 3Φ380V 50Hz 45 72 91 45

海利普變頻器HOLIP-A

HLPA00D423B 單三相220V 50Hz 0.4 1.0 2.5 0.4
HLPA0D7523B 單三相220V 50Hz 0.75 2.0 5.0 0.75
HLPA01D523B 單三相220V 50Hz 1.5 2.8 7.0 1.5
HLPA02D223B 單三相220V 50Hz 2.2 4.0 10 2.2
HLPA0D7543B 3Φ380V 50Hz 0.75 2.2 2.7 0.75
HLPA01D543B 3Φ380V 50Hz 1.5 3.2 4.0 1.5
HLPA02D243B 3Φ380V 50Hz 2.2 4.0 5.0 2.2
HLPA03D743B 3Φ380V 50Hz 3.7 6.8 8.5 3.7
HLPA05D543B 3Φ380V 50Hz 5.5 10 12.5 5.5
HLPA07D543B 3Φ380V 50Hz 7.5 14 17.5 7.5
HLPA001143B 3Φ380V 50Hz 11 19 24 11
HLPA001543B 3Φ380V 50Hz 15 26 33 15
HLPA18D543B 3Φ380V 50Hz 18.5 32 40 18.5
HLPA002243B 3Φ380V 50Hz 22 37 47 22
HLPA003043B 3Φ380V 50Hz 30 52 65 30
HLPA003743B 3Φ380V 50Hz 37 64 80 37
HLPA004543B 3Φ380V 50Hz 45 72 91 45
HLPA005543B 3Φ380V 50Hz 55 84 110 55
HLPA007543B 3Φ380V 50Hz 75 116 152 75
海利普變頻器HOLIP-C+
海利普變頻器HOLIP-CP（跑步機專用變頻器）
