| 產地 | 浙江 |
|---|---|
| 產品別名 | 激光焊接機 |
| 功率 | 6000W |
| 控制方式 | 自動 |
| 用途 | 焊接 |
| 升降控制 | 電動 |
| 品牌 | 欣睿激光 |
| 型號 | XR-FCW6000 |
產品特點：features
●電光轉換效率高達25%- 30%；極其出色的脈沖功率、能量穩定性；
The electro-optical conversion efficiency of up to 25%--30%; pulse energy stability,
●壽命長，精度高，泵浦源使用壽命>10萬小時；
High precision, long service life, the service life of pump source >10 million hours;
●速度更快，效果更完美；光束質量最優化于應用;
Faster, more perfect beam quality optimization in application;
●緊湊型結構設計；體積小，重量輕，免維護；
Compact structure design; small volume, light weight, maintenance free.
●低成本緊湊解決方案，以半導體光纖作激光發生介質，無需激光發生氣體，綠色環保。
Low cost and compact solution to the optical fiber as the laser medium, without the need for laser gas, green environmental protection;
技術參數technical parameter
|
| XR-FCW200 | XR-FCW500 | XR-FCW800 | XR-FCW1000 | XR-FCW2000 | |||
| 最大激光功率 Max. laser output power | 200W | 500W | 800W | 1000W | 2000W | |||
| 工作模式working mode | 連續波或調制 continuous or modelate | |||||||
| 激光波長 Laser wavelength | 1070nm | |||||||
| 光束質量beam quality | M2<1.1 | M2<1.15 | M2<1.2 | |||||
| 輸出功率穩定度 standard output laser power | ±2% | |||||||
| 線寬line width | <3nm | <4nm | <4~5nm | <6nm | ||||
| 電力需求 Power supply | AC220V±10% 共0條 相關評論 |
|||||||
