| 材質 | KS |
|---|---|
| 配件名稱 | PITTMAN |
| 適用范圍 | 機械設備 |
| 品牌 | AMETEK |
| 型號 | 9236 |
| 加工定制 | 否 |
View as a webpage: Applying DC Motors in Linear Motion Applications
| Diameter | Continuous Torque | Speed @ Cont. Torque | Rated Power | Voltage Range | |||
| Series | mm | inch | Nm | oz-in | RPM | watts | Vdc. |
| DC022C-1 (6212 DC Motor) | 22.0 | 0.866 | 0.0056 | 0.80 | 4700 | 2.8 | 0 - 30.3 |
| DC022C-2 (6213 DC Motor) | 22.0 | 0.866 | 0.0092 | 1.3 | 5100 | 5.1 | 0 - 30.3 |
| DC022C-3 (6214 DC Motor) | 22.0 | 0.866 | 0.014 | 2.0 | 6400 | 9.7 | 0 - 30.3 |
| DC026C-1 (8691 DC Motor) | 26.0 | 1.024 | 0.013 | 1.9 | 4900 | 7 | 0 - 30.3 |
| DC026C-2 (8692 DC Motor) | 26.0 | 1.024 | 0.017 | 2.4 | 5500 | 10 | 0 - 38.2 |
| DC026C-3 (8693 DC Motor) | 26.0 | 1.024 | 0.023 | 3.2 | 7300 | 17 | 0 - 48 |
| DC030B-1 (8222 DC Motor) | 29.85 | 1.175 | 0.011 | 1.6 | 5200 | 6.1 | 0 - 48 |
| DC030B-2 (8223 DC Motor) | 29.85 | 1.175 | 0.014 | 2.0 | 6000 | 8.9 | 0 - 48 |
| DC030B-3 (8224 DC Motor) | 29.85 | 1.175 | 0.018 | 2.6 | 8100 | 15.7 | 0 - 48 |
| DC030C-1 (8541 DC Motor) | 30.0 | 1.181 | 0.018 | 2.5 | 4200 | 7.8 | 0 - 48 |
| DC030C-2 (8542 DC Motor) | 30.0 | 1.181 | 0.040 | 5.6 | 5300 | 23 | 0 - 48 |
| DC030C-3 (8543 DC Motor) | 30.0 | 1.181 | 0.059 | 8.3 | 4500 | 30 | 0 - 48 |
| DC040B-1 (9232 DC Motor) | 40.1 | 1.580 | 0.017 | 2.4 | 5300 | 9 | 0 - 48 |
| DC040B-2 (9233 DC Motor) | 40.1 | 1.580 | 0.033 | 4.7 | 4900 | 17 | 0 - 48 |
| DC040B-3 (9234 DC Motor) | 40.1 | 1.580 | 0.043 | 6.1 | 5000 | 23 | 0 - 48 |
| DC040B-4 (9235 DC Motor) | 40.1 | 1.580 | 0.049 | 6.9 | 5400 | 28 | 0 - 48 |
| DC040B-5 (9236 DC Motor) | 40.1 | 1.580 | 0.067 | 9.5 | 4000 | 28 | 0 - 48 |
| DC040B-6 (9237 DC Motor) | 40.1 | 1.580 | 0.081 | 11.5 | 4400 | 38 | 0 - 60.0 |
| DC054B-1 (14201 DC Motor) | 54.0 | 2.125 | 0.071 | 10.0 | 3300 | 25 | 0 - 60.6 |
| DC054B-2 (14202 DC Motor) | 54.0 | 2.125 | 0.099 | 14 | 3500 | 36 | 0 - 60.6 |
| DC054B-3 (14203 DC Motor) | 54.0 | 2.125 | 0.15 | 21 | 3000 | 46 | 0 - 60.6 |
| DC054B-4 (14204 DC Motor) | 54.0 | 2.125 | 0.18 | 26 | 3200 | 62 | 0 - 60.6 |
| DC054B-5 (14205 DC Motor) | 54.0 | 2.125 | 0.22 | 31 | 2600 | 60 | 0 - 60.6 |
| DC054B-6 (14206 DC Motor) | 54.0 | 2.125 | 0.26 | 37 | 2800 | 76 | 0 - 60.6 |
| DC054B-7 (14207 DC Motor) | 54.0 | 2.125 | 0.35 | 50 | 2800 | 108 | 0.76.4 |
| DC057B-1 (ID23000 DC Motor) | 57.2 | 2.25 | 0.21 | 30 | 6000 | 101 | 0 - 60 |
| DC057B-1 (ID23001 DC Motor) | 57.2 | 2.25 | 0.21 | 30 | 6000 | 93 | 0 - 60 |
| DC057B-2 (ID23004 DC Motor) | 57.2 | 2.25 | 0.35 | 50 | 4100 | 131 | 0 - 60 |
| DC057B-3 (ID23005 DC Motor) | 57.2 | 2.25 | 0.40 | 57 | 3400 | 128 | 0 - 60 |
| DC057B-1 (ID23205 DC Motor) | 57.2 | 2.25 | 0.21 | 30 | 6000 | 101 | 0 - 60 |
| DC057B-3 (ID23206 DC Motor) | 57.2 | 2.25 | 0.40 | 57 | 3400 | 128 | 0 - 60 |
| ID23204 DC Motor | 57.2 | 2.25 | 0.40 | 57 | 3400 | 128 | 0 - 60 |
| ID23203 DC Motor | 57.2 | 2.25 | 0.40 | 57 | 4100 | 131 | 0 - 60 |
| ID23202 DC Motor | 57.2 | 2.25 | 0.21 | 30 | 6000 | 93 | 0 - 60 |
| ID23201 DC Motor | 57.2 | 2.25 | 0.21 | 30 | 6000 | 93 | 0 - 60 |
| DC083B-1 (ID33001 DC Motor) | 82.6 | 3.25 | 0.53 | 75 | 4900 | 165 | 0 - 90 |
| DC083B-2 (ID33002 DC Motor) | 82.6 | 3.25 | 0.85 | 120 | 4000 | 245 | 0 - 90 |
強的、面向市場的解決方案
德國Dunkermotoren直流電機、Dunkermotoren無刷電機、Dunkermotoren交流電機、Dunkermotoren齒輪箱、Dunkermotoren控制器、Dunkermotoren編碼器、Dunkermotoren線性系統
德國Dunkermotoren直流電機產品介紹：
有刷直流電機 GR/G
無刷直流電機 BG
交流電機 KD/DR
百葉窗驅動 D
控制器 RS/BGB
行星和渦輪式齒輪 PLG/SG
線性系統 ST
常用型號：
