用途	節電
品牌	MC4接線盒
型號	RH008

本公司供應MC4接線盒RH008雙玻幕墻太陽能接線盒、RH008質量保證，歡迎咨詢洽談。

操作簡易,快速,高性價比的組件;
  Easily accessible,Simple,Fast and cost-effectiveassembly;
此產品具有抗紫外線和高等級接觸保護的能力;
   Due to highly robustness,UV-resistance,the touch protection a high grade connection is guaranteed for many years;
可提供2軌輸入連接;
   Privide the input connector of 2 Rail;
適用于晶體硅光伏組件;
   Apply to the Crystalline PV modoule;Technical Data 技術數據：                               Rated current               額定電流                          3A
Rated voltage               額定電壓                          DC1000V(TüV ), DC600V(UL)
Number of bypass diodes   二極管個數                         0   or    1
Connection cross-section    線纜截面                          OD7.5(1.0mm2 2C)
Temperature range         溫度范圍                           -40℃ up to +80℃
Protetion degree            防護等級                           IP65
Suitable connector    適配連接器規格                           DC
Flame class                 阻燃等級                           UL94-V0
Contact material      接線盒導軌材料                           Copper,Tin plated銅,鍍錫
Insulation material    接線盒絕緣材料                           PPO
Safety class                   安全型                           ║
