| 產品類型 | 三相異步電動機 |
|---|---|
| 產品認證 | CE |
| 額定電壓 | 5.2 |
| 額定功率 | 26 |
| 額定轉速 | 500-600 |
| 品牌 | longsmotor |
| 型號 | 34HT（86BYGHT 1.2°） |
| 技術數據（Electrical Specifications）: | ||||||||||
| 型號 Series Mode | 步距角 Step Angle ( °) | 機身長 Motor Length (mm) | 電流 Rated Current (A) | 電阻 Phase Resistance ( Ω ) | 電感 Phase Inductance (mH) | 靜力矩 Holding Torque (N.cm Min) | 定位力矩 Detent Torque (N.cm Max) | 轉動慣量 Rotor Torque (g.c㎡) | 引線數 Lead Wire (No.) | 重量 Motor Weight (g) |
| 34HT6335 | 1.2 | 66 | 3.5 | 1.2 | 2.5 | 210 | 3.5 | 0.85 | 3 | 2.0 |
| 34HT6345 | 1.2 | 66 | 4.5 | 0.7 | 1.5 | 210 | 3.5 | 0.85 | 3 | 2.0 |
| 34HT6368 | 1.2 | 66 | 6.8 | 0.3 | 0.65 | 210 | 3.5 | 0.85 | 3 | 2.0 |
| 34HT7335 | 1.2 | 78 | 3.5 | 1.6 | 5.0 | 270 | 5.8 | 1.05 | 8 | 2.5 |
| 34HT7345 | 1.2 | 78 | 4.5 | 1.0 | 3.0 | 270 | 5.8 | 1.05 | 8 | 2.5 |
| 34HT7368 | 1.2 | 78 | 6.8 | 0.42 | 1.3 | 270 | 5.8 | 1.05 | 8 | 2.5 |
| 34HT9335 | 1.2 | 98 | 3.5 | 2.5 | 6.5 | 450 | 8.5 | 1.55 | 8 | 3.0 |
| 34HT9345 | 1.2 | 98 | 4.5 | 1.4 | 3.9 | 450 | 8.5 | 1.55 | 8 | 3.0 |
