Electrical Specifications(技術數據):
| 型號SeriesModel | 步距角StepAngle(°) | 機身長MotorLength(mm) | 電流RatedCurrent(A) | 電阻PhaseResistance(Ω) | 電感PhaseInductance(mH) | 靜力矩HoldingTorque(N.cm Min) | 定位力矩DetentTorque(N.cm Max) | 轉動慣量RotorInertia(g.cm2) | 引線數LeadWire(No.) | 重量MotorWeight(g) |
| 14HY24046 | 1.8 | 28 | 0.46 | 20 | 14 | 12 | 0.8 | 11 | 4 | 120 |
| 14HY2408 | 1.8 | 28 | 0.8 | 5.0 | 5.0 | 12 | 0.8 | 11 | 4 | 120 |
| 14HY2604 | 1.8 | 28 | 0.4 | 30 | 11 | 9 | 0.8 | 11 | 6 | 120 |
| 14HY34042 | 1.8 | 34 | 0.42 | 25 | 32 | 18 | 1.0 | 13 | 4 | 160 |
| 14HY3408 | 1.8 | 34 | 0.8 | 6.5 | 9.8 | 18 | 1.0 | 13 | 4 | 160 |
| 14HY3604 | 1.8 | 34 | 0.4 | 30 | 22 | 12 | 1.0 | 13 | 6 | 160 |
*We can manufacture products according to customer's requirement. 以上僅為代表性產品，派生產品可根據客戶要求制作！
