| 應用范圍 | 控制 |
|---|---|
| 產(chǎn)品系列 | T73 |
| 觸點形式 | 常開型 |
| 額定電流 | 12V |
| 額定電壓 | 10A |
| 防護特征 | 密封式 |
| 線圈功率 | 0.36W |
| 品牌 | HONHCIN |
| 型號 | HRA |
廣泛運用于家電控制器,汽車電子等電器設備
■ConTACT DATA觸點參數(shù)
Contact Form觸點形式 | 1A/1C |
|
Contact Material觸點材料 | Silver Alloy |
|
Contact Ratings觸點負載 | 1A:10A 240VAC, 15A 12VDC(TUV) 12A 120VAC/24VDC | 1C: 7A 240VAC/10A 120VAC/24VDC 5A 240VAC(TUV) |
Max Switching Voltage**大轉換電壓 | 250VAC/30VDC |
|
Max Switching Current**大轉換電流 | 15A |
|
Max Switching Power**大轉換功率 | 2770VA/240W |
|
Contact Resistance接觸電阻 | 100mΩMax | at 6VDC 1A |
Life Expectancy Electrical電氣壽命 | 100,000 | Operations(at30Operations/minute) |
Machanical機械壽命 | 10,000,000 | Operations |
■GENERAL DATA一般參數(shù)
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
|
|
| |
|
| |
|
| |
|
| |
Safety Standard安全標準 | TUV CQC UL | |
■COIL DATA線圈參數(shù)
NominalVoltage 額定電壓 (VDC) | Coil Resistance at20℃?10%(Ω) 線圈阻值 | Max Operate Voltage **大吸合電壓 VDC | Min ReleaseVoltage **小釋放電壓 VDC | Max ApplicableVoltage **大過載電壓 VDC | |
0.36W | 0.45W | ||||
3 | 25Ω |
| 2.25 | 0.3 | 3.9 |
5 | 70Ω |
| 3.75 | 0.5 | 6.5 |
6 | 100Ω |
| 4.5 | 0.6 | 7.8 |
9 | 225Ω |
| 6.75 | 0.9 | 11.7 |
12 | 400Ω |
| 9 | 1.2 | 15.6 |
18 | 900Ω |
| 13.5 | 1.8 | 23.4 |
24 | 1600Ω |
| 18 | 2.4 | 31.2 |
48 | 6400Ω?15% | 5100Ω?15% | 36 | 4.8 | 62.4 |
