| 加工定制 | 是 |
|---|---|
| 類型 | 密封圈 |
| 材質 | 聚氨酯 |
| 作用 | 軸用密封 |
| 樣品或現貨 | 樣品 |
| 是否標準件 | 標準件 |
| 使用溫度 | 100（℃） |
| 使用壓力 | 40（MPa） |
| 是否進口 | 是 |
| 適用范圍 | 油缸 |
| 性質 | 耐磨損 |
| 品牌 | 臺灣鼎基 |
| 型號 | D-10 |
| 品名 | Ø d | Ø D | h | H | 品名 | Ø d | Ø D | h | H | |
| D-10 | 22 | 32.7 | 4 | 4.3 | D-10" | 1 1/2 | 2 1/16 | 1/8 | 0.14 | |
| D-10 | 28 | 38.7 | 4 | 4.3 | D-10" | 1 1/4 | 1 13/16 | 1/8 | 0.14 | |
| D-10 | 40 | 55.5 | 6 | 6.3 | D-10" | 1 3/4 | 2 5/16 | 1/8 | 0.14 | |
| D-10 | 45 | 60.5 | 6 | 6.3 | D-10" | 2 | 2 9/16 | 1/8 | 0.14 | |
| D-10 | 50 | 65.5 | 6 | 6.3 | D-10" | 2 1/2 | 3 3/16 | 3/16 | 0.234 | |
| D-10 | 55 | 70.5 | 6 | 6.3 | D-10" | 2 1/4 | 2 15/16 | 3/16 | 0.234 | |
| D-10 | 56 | 71.5 | 6 | 6.3 | D-10" | 2 3/4 | 3 3/8 | 3/16 | 0.234 | |
| D-10 | 60 | 75.5 | 6 | 6.3 | D-10" | 3 | 3 5/8 | 3/16 | 0.234 | |
| D-10 | 63 | 78.5 | 6 | 6.3 | D-10" | 3 1/2 | 4 3/16 | 3/16 | 0.234 | |
| D-10 | 65 | 80.5 | 6 | 6.3 | D-10" | 4 | 4 5/8 | 3/16 | 0.234 | |
| D-10 | 70 | 85.5 | 6 | 6.3 | ||||||
| D-10 | 75 | 90.5 | 6 | 6.3 | ||||||
| D-10 | 80 | 95.5 | 6 | 6.3 | ||||||
| D-10 | 85 | 100.5 | 6 | 6.3 | ||||||
| D-10 | 90 | 105.5 | 6 | 6.3 | ||||||
| D-10 | 95 | 110.5 | 6 | 6.3 | ||||||
| D-10 | 100 | 115.5 | 6 | 6.3 | ||||||
| D-10 | 105 | 120.5 | 6 | 6.3 | ||||||
| D-10 | 110 | 125.5 | 6 | 6.3 | ||||||
| D-10 | 115 | 130.5 | 6 | 6.3 | ||||||
| D-10 | 120 | 135.5 | 6 | 6.3 | ||||||
| D-10 | 124 | 139.5 | 6 | 6.3 | ||||||
| D-10 | 125 | 140.5 | 6 | 6.3 | ||||||
| D-10 | 130 | 145.5 | 6 | 6.3 | ||||||
| D-10 | 135 | 150.5 | 6 | 6.3 | ||||||
| D-10 | 140 | 155.5 | 6 | 6.3 | ||||||
| D-10 | 150 | 165.5 | 6 | 6.3 | ||||||
| D-10 | 155 | 170.5 | 6 | 6.3 | ||||||
| D-10 | 160 | 175.5 | 6 | 6.3 | ||||||
| D-10 | 170 | 185.5 | 6 | 6.3 | ||||||
| D-10 | 180 | 195.5 | 6 | 6.3 |
