| 電壓 | 24V |
|---|---|
| 分類 | 步進電機 |
| 工作形式 | 轉動 |
| 執行標準 | 國標 |
| 重量 | 3kg |
| 準入認證 | ROHS |
| 產地 | 江蘇 |
| 額定電流 | 3A |
| 額定電壓 | 24V |
| 額定轉矩 | 1NM |
| 額定轉速 | 1000 |
| 極數 | 2極 |
| 類型 | 無刷直流電動機 |
| 品牌 | 常州博宏電器有限公司 |
| 型號 | 57HB56F |
| 加工定制 | 是 |
| 質量認證 | CE |
57BYGHB 1.8°兩相
| 型號 Series Model | 機身長 Motor Length | 相電壓 Rate Voltage | 相電流 Rated Current | 相電阻 Phase Resistance | 相電感 Phase Inductance | 靜力矩 Holding Torque | 引線數 Lead Wire | 轉動慣量 Rotor Inertia | 重量 Motor Weight |
| (mm) | (V) | (A) | (Ω) | (mH) | (N.M) | (NO.) | (g.cm?) | (Kg) | |
| 57HB41F05B | 41 | 6 | 0.5 | 12 | 20 | 0.4 | 4 | 120 | 0.45 |
| 57HB41F105B | 2.7 | 1.5 | 1.8 | 4 | 0.4 | 4 | |||
| 57HB51F06B | 51 | 7.2 | 0.6 | 12 | 25 | 0.7 | 4 | 275 | 0.65 |
| 57HB51F2B | 2.6 | 2 | 1.3 | 4 | 0.9 | 4 | |||
| 57HB56S06B | 56 | 12 | 0.6 | 20 | 25 | 0.8 | 6 | 300 | 0.7 |
| 57HB56F2B | 3.6 | 2 | 1.8 | 2.5 | 0.9 | 4 | |||
| 57HB64S2B | 64 | 3.4 | 2 | 1.7 | 3 | 1.0 | 6 | 360 | 0.85 |
| 57HB64S3B | 2.4 | 3 | 0.8 | 1 | 0.9 | 4 | |||
| 57HB78S1B | 78 | 8.6 | 1 | 8.6 | 18 | 1.5 | 6 | 480 | 1.1 |
| 57HB78S3PJ | 3.6 | 3 | 1.2 | 2.5 | 1.5 | 6 | |||
| 57HB78F105AB | 6.75 | 1.5 | 4.5 | 15 | 1.8 | 4 | |||
| 57HB78S3B | 3 | 3 | 1 | 1.6 | 1.4 | 6 | |||
| 57HB82E105B | 82 | 7.5 | 1.5 | 5 | 10 | 1.6 | 8 | 530 | 1.2 |
